AZ-104 Lab 4 — Week 4: Connect an Azure VM to Azure Storage Using Managed Identity (2025 Portal UI)

Series: Week 4 of the AZ-104 Learning Labs on jmcnairtech.com

Goal: Learn how to connect an Azure Virtual Machine to Azure Storage securely using Managed Identities and RBAC — no access keys, no SAS tokens, no secrets.

This is an important task as a real-world Azure Administrator skill and a key part of the AZ-104 exam.

What You’ll Learn This Week

• create a new Azure Storage Account using the 2025 portal interface

• create a private Blob container and upload a file

• deploy a Virtual Machine using the modern VM creation UI

• enable a System-Assigned Managed Identity on a VM

• assign RBAC permissions such as Storage Blob Data Reader

• access Blob Storage from inside the VM using identity-based authentication

• download blobs inside the VM with Azure CLI or PowerShell using

Prerequisites

• Active Azure subscription

• Basic familiarity with the Azure Portal

• We’ll use East US as the region (you can choose your own)

Lab Scenario (Real Azure Admin Task)

You are an Azure Administrator responsible for supporting a line-of-business application that processes files uploaded by employees.
These files—images, PDFs, and documents—are stored in an Azure Blob Storage container.

Your application server runs on a Virtual Machine, and the VM needs to:

• download files from the Blob container

• process or analyze those files (for example: resize images, scan PDFs, extract text, run scripts, etc.)

• upload results or processed outputs back to storage

Instead of using storage account keys or SAS tokens (which are hard to manage and insecure), you’ll give the VM a System-Assigned Managed Identity and assign it the Storage Blob Data Reader role.

This allows the VM to access Blob Storage securely using Azure AD authentication — no keys, no secrets, no passwords.

Step 1 — Create a Resource Group

Resource groups help you organize all related resources so you can clean up easily at the end.

1.1

In the Azure Portal search bar, type Resource groups and select it.

1.2

Click + Create.

1.3 Fill in:

• Subscription: your default

• Resource group name: rg-week4-lab

• Region: East US

Click Review + create → Create.

Step 2 — Create a New Azure Storage Account

This storage account will hold the files that your Virtual Machine needs to access securely using its Managed Identity.

2.1 — Navigate to the Storage Center

1. In the Azure Portal search bar, type Storage accounts.

2. Select Storage accounts from the results.

You will now see the new Storage Center (with tiles for different storage types).

2.2 — Choose the Storage Type (Required in 2025 UI)

• From the Storage Center categories, select Object storage.

• Then select Blob Storage.

• The Create button will now appear.

• Click + Create to begin the Storage Account wizard.

2.3 — Basics tab

Project details

• Subscription: your active subscription

• Resource group: rg-week4-lab

Instance details

• Storage account name: storweek4mcnair

• Region: East US

• Preferred storage type: Azure Blob Storage

• Performance: Standard

• Redundancy: LRS (Locally Redundant Storage)

Click Next: Advanced →

2.4 — Advanced tab

• Minimum TLS version: TLS 1.2

• Enable hierarchical namespace: Off

• SFTP, NFS, and large file shares: Off

• All other settings: leave defaults

Click Next: Networking →

2.5 — Networking tab (Updated for 2025 Portal)

Public network access

• Enable: Yes

Public access scope

• Enable from all networks

Routing preference

• Microsoft network routing (default)

Private endpoints

• Leave empty

Click Next: Data protection →

2.6 — Data protection tab

• Enable soft delete for blobs: 7 days

• Leave all other options at default

Click Next: Encryption →

2.7 — Encryption tab

• Encryption type: Microsoft-managed keys

• Enable support for customer-managed keys: Blobs and files only

• Enable infrastructure encryption: Unchecked

Click Review + Create → Create

After deployment completes, your new Storage Account is ready to use.

Step 3 — Create a Blob Container & Upload a Test File (2025 UI)

In this step, you will create a secure container inside your Storage Account and upload a sample file that your VM will access later using its Managed Identity.

3.1 — Open your new Storage Account

• After deployment finishes, click Go to resource
  or search for your storage account name:

  • storweek4mcnair

• In the left-hand menu, scroll to the Data storage section.

• Click Containers

This opens the Blob Containers page.

3.2 — Create a new Blob Container

• Click + Add Container (top-left)

• Fill in the container details:

  • Name: lab4-files

    • lowercase

    • no spaces

  • Public access level: Private (no anonymous access)

    • This ensures files can only be accessed through RBAC, identity, or SAS.

• Click Create

3.3 — Upload a test file

Inside your container:

• Click lab4-files

• Click Upload at the top

• Browse your computer for a small sample file, for example:

  • test.txt

  • document.pdf

• Click Upload

The file will now appear inside your container.

3.4 — Confirm the container is private

You can verify private access by:

• Clicking the file you uploaded

• Copying the Blob URL

• Pasting it into a new browser tab

You should see: “Public access not permitted”

This is expected — the container is private and cannot be accessed without identity-based authentication or a SAS token.

Step 4 — Create a Virtual Machine with a System-Assigned Managed Identity

This VM will act as your application or processing server.
Later in the lab, it will authenticate to Blob Storage without keys or SAS tokens — using Azure AD and RBAC instead.

4.1 — Open the VM creation blade

• In the Azure Portal search bar, type Virtual machines

• Click Virtual machines

• Click + Create → Azure virtual machine

This opens the modern VM creation wizard.

4.2 — Basics Tab

Fill out the fields as follows:

Instance details

• Virtual machine name: vm-week4-client

• Region: (US) East US

• Availability options:

  • Select No infrastructure redundancy required
    (This avoids zone restrictions and keeps the lab simple.)

Security type

• Standard
  (Trusted Launch is not needed for this scenario.)


• Click See all images

• Search for and select:
  Windows Server 2025 Datacenter: Azure Edition (Gen 2)
  (Easier for RDP and PowerShell testing.)

VM architecture

• x64

Size

• Click See all sizes

• Choose:

  • Standard_B2s (recommended), or

  • Standard_B1s (cheapest option)

Administrator account

• Username: azureuser

• Password: a strong password you will remember

Inbound port rules

• Public inbound ports: Allow selected ports

• Select inbound ports: RDP (3389)

Click Next: Disks

4.3 — Disks Tab

• OS disk type: Standard SSD

• Leave all other settings at default

Click Next: Networking

4.4 — Networking Tab

• Virtual network: auto-created default VNet

• Subnet: default

• Public IP: Enabled

• NIC network security group: Basic

• Inbound port: RDP (3389)

Click Next: Management

4.5 — Management Tab (Enable Managed Identity)

Scroll to the Identity section:

• System-assigned managed identity: On

This identity allows the VM to authenticate to Azure Storage securely later in the lab.

Leave all other settings at default:

Click Review + Create
Then click Create

Deployment will complete in 1–3 minutes.

Your VM is now deployed and has a system-assigned managed identity enabled.
This identity is what will securely access the Blob Storage container in the next steps.

Step 5 — Assign the VM Access to Blob Storage (RBAC)

Now that your VM has a System-Assigned Managed Identity, you must grant that identity the correct permissions so it can access your Blob Storage.

Azure uses Role-Based Access Control (RBAC) for this.
You will assign the VM’s identity the Storage Blob Data Reader role.

5.1 — Open Your Storage Account

• In the Azure Portal search bar, type Storage accounts

• Select your storage account: storweek4mcnair

• In the left-hand menu, click Access control (IAM)

5.2 — Add a Role Assignment

• Click + Add → Add role assignment

• Under Role, search for:

  • Storage Blob Data Reader

• Select the role and click Next

This role allows the VM to read blobs but not upload or delete.

5.3 — Assign Role to the VM’s Managed Identity

Under Assign access to, choose Managed identity

• Click + Select members

• In the identity browser:

  • Select Virtual machine

  • Choose vm-week4-client

• Click Select

• Click Review + assign



  5.4 — Confirm Role Assignment

  After the assignment completes:

  • You should now see Storage Blob Data Reader

  • Assigned to: vm-week4-client (Managed Identity)

  • Scope: This storage account

This means the VM can now authenticate to Blob Storage using its Azure AD identity.

If you want your VM to also upload files, you can assign Storage Blob Data Contributor

But for this lab, Reader is enough.

Step 6 — Connect to the VM and Access Blob Storage Using PowerShell (Data-Plane, Managed Identity)

In this step, you’ll RDP into the VM, sign in with its Managed Identity, create a data-plane storage context, list containers, and download a blob — all without keys or SAS.

6.1 — Connect to the Virtual Machine (RDP)

• In the Azure Portal, go to Virtual machines

• Click vm-week4-client

• Click Connect → RDP

• Click Download RDP file

• Open the RDP file

• Log in using:

  • Username: azureuser

  • Password: the one you created

Once logged in, wait a moment for Windows Server to load.

6.2 — Open PowerShell on the VM

• Click Start

• Search for PowerShell

• Right-click → Run as administrator

This ensures all commands run properly.

6.3 — Install the Az PowerShell Module (if needed)

If Connect-AzAccount is not recognized, install the module:

Install-Module -Name Az -Repository PSGallery -Force

Import-Module Az

6.4 — Authenticate Using the VM’s Managed Identity

Run this inside PowerShell: Connect-AzAccount -Identity

You should see output similar to:

This means the VM is now authenticated to Azure using its Managed Identity.

No passwords.
No keys.
No SAS tokens.
Modern Azure Admin technique.

6.5 — Build a data-plane Storage Context (no management rights needed)

# Replace with your storage account name
$accountName = "storweek4mcnair"

# Create a context that uses the current connected identity
$ctx = New-AzStorageContext -StorageAccountName $accountName -UseConnectedAccount

This avoids management-plane APIs (like Get-AzStorageAccount) and uses only the blob data plane, which your Storage Blob Data Reader role allows.

6.6 — List containers (data plane)

Get-AzStorageContainer -Context $ctx

---

6.7 — Download a blob (data plane)

Replace the blob name with the file you uploaded earlier (e.g., test.txt, photo.jpg)

$container = "lab4-files"

$blobName = "<yourfilename>"

$destPath = "C:\Users\azuser\Desktop\$blobName"

Get-AzStorageBlobContent -Container $container -Blob $blobName -Destination $destPath -Context $ctx

6.8 — Verify the Downloaded File on the VM

Now that you downloaded the blob onto your VM, let’s confirm it’s there and readable.

Get-Item "C:\Users\azuser\Desktop$blobName"

At this point, you have fully validated that:

• The VM authenticated using Managed Identity

• RBAC allowed access

• Your Storage Blob Data Reader assignment is working

• The VM downloaded the file through Azure AD (not keys or SAS)

Week 4 Summary — Azure VM to Blob Storage Access with Managed Identity

In this lab, you built a complete, real-world Azure scenario: a Virtual Machine securely accessing a Blob Storage container using a System-Assigned Managed Identity.

This is the modern, recommended way to authenticate Azure workloads — without keys, without SAS tokens, and without storing any secrets inside scripts.

By the end of the lab, you successfully:

• created a new Storage Account using the updated 2025 Azure Portal

• created a private Blob container and uploaded a test file

• deployed a Windows Server VM with a System-Assigned Managed Identity

• connected to the VM via RDP and installed the Az PowerShell modules

• authenticated the VM using Connect-AzAccount -Identity

• built a data-plane storage context using the VM’s identity

• listed containers and downloaded a blob directly to the VM desktop

• accessed everything through Azure AD and RBAC only

This lab mirrors exactly how Azure administrators secure compute-to-storage communication in real enterprise environments. Please stay tuned for more labs if you’re interested in Azure or currently studying for the AZ-104 certification from Microsoft.
